6300 Series

Single row deep groove ball bearing housings are the most widely used bearing types: 1. Basic design of open bearing 2. Sealed bearings 3. ICOS oil-sealed bearing unit

Category：

Deep groove ball bearings

Whatsapp:+86-18462269993

Email:delitong@cndltbearing.com

Inquire

6300 Series

Single row deep groove ball bearing housings are the most widely used bearing types:
1. Basic design of open bearing
2. Sealed bearings
3. ICOS oil-sealed bearing unit
4. Bearings with snap grooves, with or without snap rings
Other deep groove ball bearings for special applications:
1. Hybrid ceramic bearings
2. Electrically insulated bearings
3. High temperature bearing
4. Solid oil bearing
5. Sensor bearing

Bearing Number	d mm	D mm	H mm
6300	10	35	11
6301	12	37	12
6302	15	42	13
6303	17	47	14
6304	20	52	15
6305	25	62	17
6306	30	72	19
6307	35	80	21
6308	40	90	23
6309	45	100	25
6310	50	110	27
6311	55	120	29
6312	60	130	31
6313	65	140	33
6314	70	150	35
6315	75	160	37
6316	80	170	39
6317	85	180	41
6318	90	190	43
6319	95	200	45
6320	100	215	47
6321	105	225	49
6322	110	240	50
6324	120	260	55
6326	130	260	58
6328	140	300	62
6330	150	320	65
6332	160	344	68
6334	170	360	72
6336	180	380	75
6338	190	400	78
6340	200	420	80

Warehousing and delivery

Shandong Delitong Bearing Co., Ltd., founded in 2002, is located in the industrial zone of Linqing, Shandong Province. It is a bearing production base integrating design, production and sales. The company has strong technical strength, complete measurement, physical and chemical inspection, and testing methods, strong product research and development capabilities, and technological innovation capabilities. It can design and produce bearings for various industries with 0, 2, 3, 6, 7, 8, 9, 7 types, 3 accuracy levels, and over 4000 specifications for various purposes. The products are widely used in industries such as metallurgy, shipbuilding, petroleum, chemical industry, mining, coal, hydropower, heavy machinery, etc.
