Single row deep groove ball bearing is the most representative structure of rolling bearings and has a wide range of uses. The raceways located on the inner ring and the outer ring have an arc cross section with a radius slightly larger than the radius of the rolling ball. In addition to bearing radial load, it can also bear axial load in two directions. Low friction torque, most suitable for applications requiring high speed rotation, low noise and low vibration. This kind of bearing, in addition to the open type, also has a bearing with a steel plate dust cover, a bearing with a rubber seal, or a bearing with a snap ring attached to the outer diameter of the outer ring. Generally, steel stamping cages are used. Mainly applicable cage: steel stamping cage (wave shape, crown shape...single row; S shape...double row)

Category：

Deep groove ball bearings

Whatsapp:+86-18462269993

Email:delitong@cndltbearing.com

Related
Inquire

6200 Series

Single row deep groove ball bearing is the most representative structure of rolling bearings and has a wide range of uses. The raceways located on the inner ring and the outer ring have an arc cross section with a radius slightly larger than the radius of the rolling ball. In addition to bearing radial load, it can also bear axial load in two directions. Low friction torque, most suitable for applications requiring high speed rotation, low noise and low vibration. This kind of bearing, in addition to the open type, also has a bearing with a steel plate dust cover, a bearing with a rubber seal, or a bearing with a snap ring attached to the outer diameter of the outer ring. Generally, steel stamping cages are used. Mainly applicable cage: steel stamping cage (wave shape, crown shape...single row; S shape...double row)



Bearing Number

d mm

D mm

H mm

6201

12

32

10

6202

15

35

11

6203

17

40

12

6204

20

47

14

6205

25

52

15

6206

30

62

16

6207

35

72

17

6208

40

80

18

6209

45

85

19

6210

50

90

20

6211

55

100

21

6212

60

110

22

6213

65

120

23

6214

70

125

24

6215

75

130

25

6216

80

140

26

6217

85

150

28

6218

90

160

30

6219

95

170

32

6220

100

180

34

6221

105

190

36

6222

110

200

38

6224

120

215

40

6225

130

230

40

6226

130

230

40

6228

140

250

42

6230

150

270

45

6232

160

290

48

6234

170

310

52

6236

180

320

52

6238

190

340

55

6240

200

360

58

Warehousing and delivery

Shandong Delitong Bearing Co., Ltd., founded in 2002, is located in the industrial zone of Linqing, Shandong Province. It is a bearing production base integrating design, production and sales. The company has strong technical strength, complete measurement, physical and chemical inspection, and testing methods, strong product research and development capabilities, and technological innovation capabilities. It can design and produce bearings for various industries with 0, 2, 3, 6, 7, 8, 9, 7 types, 3 accuracy levels, and over 4000 specifications for various purposes. The products are widely used in industries such as metallurgy, shipbuilding, petroleum, chemical industry, mining, coal, hydropower, heavy machinery, etc.
